Appendix B - Message Action List
This appendix lists all the messages that are likely to be displayed at the VIGILON control panel /
Network Node. There are some fault events that are not self clearing and will require manual
intervention.
Clearable fault events
The following faults are identified as clearable fault events.
¨
FLASH corrupt
¨
Invalid device configuration
¨
Too many errors
Can be cleared but will not reset the counters.
¨
Unrecoverable Tx fault
¨
Checksum error
FLASH Configuration data and FLASH in sensors
¨
NVM recovery failures or map mis-match
How to clear a clearable fault event
To clear the fault at the control panel press the Menu on/Off button -> [Test/Eng] -> [UserCode]
-> enter your PIN (where necessary) -> <etc> -> [Config]->[Clear] -> [Fault] -> [Enter], then
scroll through to the fault you wish to clear and select [clear].
Latching fault events
The following faults are identified as latching events.
¨
Slave devices lost
¨
Loop allocation fault
¨
Invalid loop configuration
How to clear a latching fault event
To clear a latching fault it is necessary to re-allocate the loop circuit.
Repairable fault events
Repairable fault events are those that require manual intervention to clear the fault, for example
after following tests:
¨
Loop (partial) short circuit.
¨
Ground break
How to clear a repairable fault event
To repair the fault at the control panel press the Menu on/Off button -> [Test/Eng] -> [UserCode]
-> enter your PIN (where necessary) -> [Loop]-><etc> -> <etc> -> [Repair] -> [Loop] -> enter
the loop number on which the fault resides -> [Enter].
