Honeywell Vigilon 4 loop User Manual

S-Quad Heat sensor STATES
# - factory default STATE
State Definition / Class Application in / Suitable for:
Sensitivity
a-high- to-e-none
State 0#
Class A1 heat Area having high levels of smoke, dust or steam a
State 13 Class A2 heat Area where there is moderate temperature changes plus dust, smoke or steam present b
State 5 High temperature Class B heat Area having high ambient temperature plus dust, smoke or steam present c
State 6 High temperature Class BS heat - with
no rate of rise component
Area where there is rapid temperature changes plus dust, smoke or steam present d
State 15 No detection e
S-Quad Dual Optical & Heat / Optical & Heat sensor STATES
# - factory default STATE
State Definition / Class Application in / Suitable for:
Sensitivity
a-high- to--j-none
State 3 High sensitivity optical,
Class A1 heat
Clean area or environment, where early detection is required a
State 4 Medium sensitivity with no optical spike
protection, Class A1 heat
General area as State 0 with less immunity to steam and dust to facilitate witness test b
State 0#
Medium sensitivity optical, Class A1
heat
General area c
State 8 Delayed medium sensitivity optical,
Class A1 heat
General application in area with transient steam, dust or smoke present d
State 5 Medium sensitivity optical, Class B heat Area having high ambient temperature with low dust, smoke or steam present e
State 2 Low sensitivity optical, Class A1 heat Areas with moderate dust, smoke or heat during working hours when used with timing function f
State 11 Low sensitivity optical,
Class B heat
Area having high ambient temperature, plus where moderate dust, smoke or steam present g
State 6 Low sensitivity optical,
Class BS heat
Area having high ambient temperature that changes, plus moderate dust, smoke or steam
present
h
State 12 Class A1 heat only Area where smoke, dust or steam occurs at times I
State 15 No detection j
4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms. 75
Vigilon 4/6 loops & Compact (VA) panels & network nodes
S-Quad Sensor with Strobe - STATES (legacy devices)
