Preface
This is the seventh issue of the Commissioning instructions for the fire alarm system based on the
EN54/BS Vigilon 4/6 loop panels, Vigilon Compact panel (&VA) (with network capability)
and Vigilon Network nodes. This manual covers EN panels having Master Control Card / Master
Control Board software at version 4.53 or higher and BS panels having Master Control Card
software at version 3.97 or higher. It also covers FARE, FPE and Part 23 devices.
Associated documents
The Vigilon control panels and network nodes are supplied with respective copies of the operating
and installation instruction manuals:
EN54 Vigilon 4/6-loop panel based system - Installation instructions & Operating instructions
EN54 Vigilon Compact panel based system - Installation instruction & Operating instructions
EN54 Vigilon Compact Voice Alarm panel - Installation instructions & Operating instructions
Vigilon Compact Network node - Installation instructions
Vigilon Network Node - Installation instructions
Commissioning tool - User guide
Conventions
"
This is a note to highlight important text that is normally hidden in the main text.
&
This is either a caution to prevent damage to the equipment or a
warning to inform of dangerous conditions that may result in injury or death.
Symbol Keys
What you will see.
What you will hear.
ACC Audio Control Card
ADC Analogue to digital
converter
C Common
CH channel
CO Carbon monoxide
DAU Distributed Amplifier Unit
DEV Device
DIL Dual in line
DKC Display keyboard card
DPCO Double pole change over
(relay contacts)
EEPROM Electrically Erasable
Programmable ROM
EOL End of line
FAB First action byte
IO or I/O Input Output channels
IP Ingress protection
LED Light emitting diode
LRT Loop Radio Transceiver
LPC Loop processor card
LPCB Loss prevention council
certification board
MCB Master control board
(CARD 0)
MCC Main control card or Main
controller card (CARD 0)
MCP Manual call point
Mpeg Moving picture expert
group
N/C or NC Normally closed
N/O or NO Normally open
NVM Non Volatile Memory
(CARD14)
O/C or OC Open circuit
PA Public Address
PCB Printed circuit board
PIN Personal identification
number
(usercode, password,
access code)
PSU Power supply unit
PTT Press to Talk
PVC Polyvinyl chloride
QB Quick blow (fuse)
S/C or SC Short circuit
SAB Second action byte
SAFE Software addressed
firmware encoded
SPCO Single pole change over
relay contacts
SPL Sound pressure level
T Anti-surge (fuse)
USB Universal serial bus
VA Voice Alarm
