Honeywell Vigilon 4 loop User Manual

S4 Dual OH/Voice Sounder 1 - Optical (forward)
2 - Heat
4 - Optical (backward)
25
66
40
S4 OH Sensor Sounder 1 - Optical (forward)
2 - Heat
25
66
S4 Dual OH Sensor Sounder 1 - Optical (forward)
2 - Heat
4 - Optical (backward)
25
66
40
S4 Heat Sensor Sounder 2 - Heat 66
S4 Dual OH CO Sensor 1 - Optical (forward)
2 - Heat
3-CO
4 - Optical (backward)
25
66
25
40
Beam Transmit
0
Beam Receive 2
150 - 170
Typical new Time average values for legacy 34K sensors
Device type 34K Analogue Channel number
Time average Tnew
Optical
Heat
1
2
200 - 235
180 - 210
Heat 2
180 - 210
4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms. 69
Vigilon 4/6 loops & Compact (VA) panels & network nodes
Device checks
