XNX Universal Transmitter
Section 5 - Warnings/Faults
110
Warning Description
Applicable
Sensors
Latching / Non-Latching
Frequency of Diag-
nostic
Event History Data Action For Resolution
W015
SensorInter-
nalFailure
Optima,
Excel
LatchingandNon-
latching
XNXpollssensor
every2seconds,
diagnosticfre-
quencycontrolled
bysensor
Sensorfaultor
warningcode
(Note4)
RemoveandreturntoHoneywellforrepair
Sensorhasan
internalsoft-
wareerror
Excel Latching
XNXpollssensor
every2seconds,
diagnosticfre-
quencycontrolled
bysensor
Sensorfaultor
warningcode
(Note4)
CycleExcelpowerandconrm“faultcleared�”Ifnot,replacesensor
W016
SensorInstal-
lationNot
Complete
Excel Non-latching
XNXpollssensor
every2seconds,
diagnosticfre-
quencycontrolled
bysensor
Sensorfaultor
warningcode
(Note4)
CheckExcelalignment�Performazerocalibration�
W018
GeneralDiag-
nostics
Optima,
Excel
Non-latching
XNXpollssensor
every2seconds,
diagnosticfre-
quencycontrolled
bysensor
Sensorfaultor
warningcode
(Note4)
Checksensorconnections,checksensoroperation,treplacementsen-
sor,replacepersonaltyboard�
W019
SensorInter-
nal5VPower
SupplyDefect
Excel Non-latching
XNXpollssensor
every2seconds,
diagnosticfre-
quencycontrolled
bysensor
Sensorfaultor
warningcode
(Note4)
RemoveandreturntoHoneywellforrepair
W020
ForcedmA
Timeout
All Latching 1second ForcedmA
IndicatesthataforcedmAconditionwasleftonformorethan15
minutes�NoactionrequiredasmAoperationwillbereturnedtonormal
automatically
W021
ForcedRelay
Timeout
All Latching 1second
Forced
relaystatus,
1=Alarm1on,
2=Alarm2on,
4=Faulton
Indicatesthataforcedrelayconditionwasleftonformorethan15
minutes�Noactionrequiredasrelayoperationwillbereturnedtonormal
automatically
W022
mVSensor
Calibration
Needed
mV Latching
Whenuser
changessensor
typeorgas
1=newsensor,
2=changed
personality,
3=changedgas
GeneratedafteracceptinganewmVsensororchangingthemVsensor
typeorchangingthemVgasselection�Thisisawarningtouserthata
spancalibrationshouldbeperformed�Ifaspancalibrationisnotper-
formed,thedefaultcalibrationvalueswillbeused�
