Honeywell XNX Technical Manual

XNX Universal Transmitter
Section 2 - Installation and Operation
83
2.6.2
?
Information Menu
TheInformationMenuDisplaysthecurrentstatusinformationfor
theseparmeters:
Symbol Description Symbol Description
ShowAlarm/FaultStatus ShowGasData
ShowDate/Time ShowRange/AlarmSettings
ShowTransmitterData ShowmALevelSettings
?
ShowTransmitterStatus ShowRelaySettings
ShowSensorData ShowFieldbusSettings
?
ShowSensorStatus
?
ShowEventHistory
Alarm/Fault Status
Figure 163. Alarm/Fault Status Screen
SelectAlarm/FaultStatustodisplaytheAlarm/FaultStatus
screenallowingfaultsandalarmstobereset�
Figure 164. Alarm/Fault Status Screen
The‘ü’willbehighlighted�Select
✓
toresetallfaultsandalarms
generatedbythetransmitterthenreturntotheAlarm/FaultStatus
screen�Selectthe
✖
switchtoreturntotheAlarm/FaultStatus
screenwithoutresettingfaultsoralarms�
Date & Time
 
Figure 165. Date/Time Screens
TheDateandTimescreensdisplaythedateandtimeinthe
formatscurrentlysetonthetransmitter�Tosetthetimeanddate
seeSetDate&Time�
Transmitter Data
Figure 166. Transmitter Data Screen
Usingthe   switches,t heTransmitterDatadisplaystheID,part
number,serialnumber,andversionnumberofthermware�
   
Figure 167. Transmitter ID, Part Number and Serial Number Screens

Honeywell XNX Specifications

General

Ingress Protection	IP66/67
Product Type	Universal Transmitter
Enclosure Rating	IP66/67
Display	LCD
Communication Protocols	HART, Modbus, Foundation Fieldbus
Power Supply	24 VDC nominal, 18-32 VDC
Operating Temperature	-40°C to +65°C (-40°F to +149°F)
Material	Aluminum or Stainless Steel
Gas Types	Toxic, Oxygen, and Combustible gases
Output	4-20 mA
Relays	3 programmable relays
Approvals	ATEX, IECEx, UL, CSA
Sensor Compatibility	Electrochemical, catalytic, infrared, and other sensor types
