Honeywell XNX Technical Manual

XNX Universal Transmitter
Appendix A - HART
®
Protocol
177
A.1.3 Handheld Online Menu
WhenHARTcommunicationisestablishedwiththeXNX,theRootmenuisdisplayed:
Main Menu Key Sub Menus
Online...
1DeviceSetup
2Concentration0.00
%LEL
3PVAlrmTyp
4MonitoringStateNormalMonitoring
5ResetAlarmFault(s)None
6GasNameMethane
7SensorTypeOptima
Device Setup...
1UserLogin
2XNXDisplay...
3DisplayMenu...
4TestMenu...
5Calibration...
6Configuration...
7DeviceStatus...
8DetailedSetup...
9Review
Current Login Level: Default
Want to change Login Level
1Logout[Level0]
2Login[level1/2/3]
3Exit
Online...
1DeviceSetup
2Concentration0.00
%LEL
3PVAlrmTyp
4MonitoringStateNormalMonitoring
5ResetAlarmFault(s)None
6GasNameMethane
7SensorTypeOptima
Device Setup...
1UserLogin
2XNXDisplay...
3DisplayMenu...
4TestMenu...
5Calibration...
6Configuration...
7DeviceStatus...
8DetailedSetup...
9Review
XNX Display...
1Concentration0.00%LEL
2PVAlrmTypNone
3Fault/WarnNumberF
4MonitoringStateNormalMonitoring
5TimeDateFormatmm/dd/yyhh:mm:ss
6TimeDateStamp09/18/0811:57:57
7GasNameMethaneLEL
Online...
1DeviceSetup
2Concentration0.00
%LEL
3PVAlrmTyp
4MonitoringStateNormalMonitoring
5ResetAlarmFault(s)None
6GasNameMethane
7SensorTypeOptima
Device Setup...
1UserLogin
2XNXDisplay...
3DisplayMenu...
4TestMenu...
5Calibration...
6Configuration...
7DeviceStatus...
8DetailedSetup...
9Review
Display Menu...
1ResetAlarmFaults
2EventHistory
3DisplayBasicInfo...
4DisplaySWInfo...
5DisplayOpticalPerformance
6DisplaymASettings
7DisplayAlarmSettings
8DisplayMaintenanceStatus
9DisplayInstallationStatus
Display Basic Info...
1GasName
MethaneLEL
2XNXIDSOUTH
TOWER
XNX HART Basic Menus (cont’d)


Honeywell XNX Specifications

General

Ingress Protection	IP66/67
Product Type	Universal Transmitter
Enclosure Rating	IP66/67
Display	LCD
Communication Protocols	HART, Modbus, Foundation Fieldbus
Power Supply	24 VDC nominal, 18-32 VDC
Operating Temperature	-40°C to +65°C (-40°F to +149°F)
Material	Aluminum or Stainless Steel
Gas Types	Toxic, Oxygen, and Combustible gases
Output	4-20 mA
Relays	3 programmable relays
Approvals	ATEX, IECEx, UL, CSA
Sensor Compatibility	Electrochemical, catalytic, infrared, and other sensor types
