Honeywell XNX Technical Manual

XNX Universal Transmitter
Appendix A - HART
®
Protocol
178
Main Menu Key Sub Menus
Online...
1DeviceSetup
2Concentration0.00
%LEL
3PVAlrmTyp
4MonitoringStateNormalMonitoring
5ResetAlarmFault(s)None
6GasNameMethane
7SensorTypeOptima
Device Setup...
1UserLogin
2XNXDisplay...
3DisplayMenu...
4TestMenu...
5Calibration...
6Configuration...
7DeviceStatus...
8DetailedSetup...
9Review
Display Menu...
1ResetAlarmFaults
2EventHistory
3DisplayBasicInfo...
4DisplaySWInfo...
5DisplayOpticalPerformance
6DisplaymASettings
7DisplayAlarmSettings
8DisplayMaintenanceStatus
9DisplayInstallationStatus
Display SW Info...
1Devid
1081234
2Flddevrev
1
3SensorS/wVe
r48
4Sensors/n
0
5GasName
MethaneLEL
6XNXIDSOUTH
TOWER
Online...
1DeviceSetup
2Concentration0.00
%LEL
3PVAlrmTyp
4MonitoringStateNormalMonitoring
5ResetAlarmFault(s)None
6GasNameMethane
7SensorTypeOptima
Device Setup...
1UserLogin
2XNXDisplay...
3DisplayMenu...
4TestMenu...
5Calibration...
6Configuration...
7DeviceStatus...
8DetailedSetup...
9Review
Display Menu...
1ResetAlarmFaults
2EventHistory
3DisplayBasicInfo...
4DisplaySWInfo...
5DisplayOpticalPerformance
6DisplaymASettings
7DisplayAlarmSettings
8DisplayMaintenanceStatus
9DisplayInstallationStatus
Display Optical Performance...
1SignalStrength
0.96
2RefSigStrength
1.12
3SamSigStrength
1.06
4Baseline
0.92
5DynamicReserve
96%
6WindowTemp
28degC
XNX HART Basic Menus (cont’d)


Honeywell XNX Specifications

General

Ingress Protection	IP66/67
Product Type	Universal Transmitter
Enclosure Rating	IP66/67
Display	LCD
Communication Protocols	HART, Modbus, Foundation Fieldbus
Power Supply	24 VDC nominal, 18-32 VDC
Operating Temperature	-40°C to +65°C (-40°F to +149°F)
Material	Aluminum or Stainless Steel
Gas Types	Toxic, Oxygen, and Combustible gases
Output	4-20 mA
Relays	3 programmable relays
Approvals	ATEX, IECEx, UL, CSA
Sensor Compatibility	Electrochemical, catalytic, infrared, and other sensor types
