Section 1 - Introduction
18
Wand
Instruction
Decal
Figure 10. Operation decal
Theswitchisactuatedbytheuxlinesbetweenthepolesofthe
magnet�Thisactuationmethodprovidesthemostconsistent
response�
Avisualindicationoftheswitchactuationwillappearinthe
lowerrightcorneroftheXNXdisplayeachtimetheswitchis
activated�
Insomemenuswheredisplayedvaluescanbechanged,the
magnetmustbeswipedovertheswitchtocausethenumeralon
thedisplaytoadvancethroughtheavailablevalues�Usethe
✖

switchtoreturntoapreviousmenuoreld�
Forthepurposesofthismanual,theinstructiontouse
✓
,
✖
, or ,meanstoactivatetherelevantmagneticswitchas
describedabove�
Power LED (green)
Alarm LED (red)
Fault LED (yellow)
Escape
Move Left
Decement Value
Move Right
Increment Value
Switch Actuation
Visual Indicator
Enter/Accept
Figure 11. Front panel display of the XNX transmitter
1.4.1 Controls and Navigation
Command Description
✓
Enter/Accept
TheEnter/Acceptswitchisusedtoaccessmenus,
acceptchangesandtoanswer“yes”tosystem
prompts�
✖
Escape/Back
TheEscape/Backswitchisusedtoreturntoprevious
menusortoanswer“no”tosystemprompts�
MoveLeft/
DecrementValue
TheLeft/Decrementarrowisusedtomovethrough
menuoptionsordecrementvalueswhenenteringtext
ornumbers�
MoveRight/
IncrementValue
TheRight/Incrementarrowisusedtomovethrough
menuoptionsorincrementvalueswhenenteringtextor
numbers�


Honeywell XNX Specifications

General

Ingress Protection	IP66/67
Product Type	Universal Transmitter
Enclosure Rating	IP66/67
Display	LCD
Communication Protocols	HART, Modbus, Foundation Fieldbus
Power Supply	24 VDC nominal, 18-32 VDC
Operating Temperature	-40°C to +65°C (-40°F to +149°F)
Material	Aluminum or Stainless Steel
Gas Types	Toxic, Oxygen, and Combustible gases
Output	4-20 mA
Relays	3 programmable relays
Approvals	ATEX, IECEx, UL, CSA
Sensor Compatibility	Electrochemical, catalytic, infrared, and other sensor types
