Honeywell XNX Technical Manual

XNX Universal Transmitter
Section 2 - Installation and Operation
59
Figure 72. Set Time Screen
Usethe  switchestonavigatetotheü�Selectittosavethe
changes�Ifü isnotselected,nochangeswillbesaved�
Figure 73. Accept Time-Date Changes
Whenthenewsettingshavebeensaved,the“Settings
Accepted”screenwillbedisplayed�
Figure 74. Time-Date Settings Accepted
The remainder of this section requires Level 2 security access.
Set mV Sensor Type
Figure 75. Set mV Sensor Type Screen
SetmVSensorTypesetstheidentityofthetypeofmVsensor
attachedtothetransmitter�TheavailablemVsensortype
selectionsare:
Sensor Description
MPD-IC1(5%V) MPDCarbonDioxide5%Vol
MPD-IV1(5%V) MPDMethane5%Vol
MPD-IV1(100%L) MPDMethane100%LEL
MPD-IF1(100%L) MPDFlammable100%LEL
MPD-CB1(100%L) MPDFlammable100%LEL
705-HT(20%L) 705Flammable20%LEL(High-Temp)
705-HT(100%L) 705Flammable100%LEL(High-Temp)
705-STD(100%L) 705Flammable100%LEL
SP-HT(20%L) SensepointFlammable20%LEL(High-Temp)
SP-HT(100%L) SensepointFlammable100%LEL(High-Temp)
SP-STD(100%L) SensepointFlammable100%LEL
SP-PPM(10%L) SensepointFlammablePPM(10%LELequiv)
SP-PPM SensepointFlammablePPM
SP-HT-NH3 SensepointAmmonia30,000PPM


Honeywell XNX Specifications

General

Ingress Protection	IP66/67
Product Type	Universal Transmitter
Enclosure Rating	IP66/67
Display	LCD
Communication Protocols	HART, Modbus, Foundation Fieldbus
Power Supply	24 VDC nominal, 18-32 VDC
Operating Temperature	-40°C to +65°C (-40°F to +149°F)
Material	Aluminum or Stainless Steel
Gas Types	Toxic, Oxygen, and Combustible gases
Output	4-20 mA
Relays	3 programmable relays
Approvals	ATEX, IECEx, UL, CSA
Sensor Compatibility	Electrochemical, catalytic, infrared, and other sensor types
