Honeywell XNX Technical Manual

XNX Universal Transmitter
Section 6 - Specications
147

XNX Certications - XNX-BT**.***** Part Number Series
XNX Part Number Series
XNX Transmitter
IR Personality
XNX Transmitter mV Personality
XNX Transmitter EC
Personality
Options
XNX-BTSI-*****
XNX-BTAI-*****
XNX-BTPI-*****
XNX-BTSV-*****
XNX-BTAV-*****
XNX-BTPV-*****
XNX-BTSE-*****
XNX-BTAE-*****
XNX-BTPE-*****
With Generic 20 mA Input With Optima Plus With Searchline Excel MPD-UTCB1 (Cat Bead) MPD-UTIV1 (IR Methane) MPD-UTIF1 (IR Flam) MPD-UTIC1 (IR CO2 ) with 705 HT With XNXXSO1FM O
2
Cartrdige
With XNXXSH1FM H
2
S Cartridge
With XNXXSC1FM CO Cartridge SO
2
, NH
3
, CL
2
, ClO
2
, NO, NO
2
, H
2
PPM HCL, HCN, HF, O
3
, PH
3
Modbus Relays Local HART Foundation Field Bus
UL Classied
UL 1203 T T T T T T T T T T T T T T T T
UL 913-7th Edition Applies to Local HART Option) N/A N/A N/A N/A N/A N/A N/A N/A T T T T N/A N/A T N/A
INMETRO
TÜV Rheinland
ABNT NBR IEC 60079-0:2006 T T T T T T T T T T T T T T T T
ABNT NBR IEC 60079-1:2007 T T T T T T T T T T T T T T T T
ABNT NBR IEC 60079-11:2009 N/A N/A N/A N/A N/A N/A N/A N/A T T T T N/A N/A T N/A
ABNT NBR IEC 60529-:2005 T T T T T T T T T T T T T T T T
FM Listed
Standard referenced in notes 1, 2, 3
N/A N/A N/A N/A N/A N/A 3 N/A 1 2 3 N/A
T T T T
FM 6310 / 6320
N/A T N/A T N/A N/A N/A T N/A N/A N/A N/A
T T T T
FM 6325
N/A N/A T N/A N/A N/A N/A N/A N/A N/A N/A N/A
T T T T
FM 6340
N/A N/A N/A N/A N/A N/A T N/A N/A N/A N/A N/A
T T T T
T = 3/4 NPT threaded Transmitters & Adapters
N/A = Not Applicable
1. ANSI/ISA 92.04.01, Part 1 2007
2. ISA 92.0.01, Part 3 1998
3. FM 6340

Honeywell XNX Specifications

General

Ingress Protection	IP66/67
Product Type	Universal Transmitter
Enclosure Rating	IP66/67
Display	LCD
Communication Protocols	HART, Modbus, Foundation Fieldbus
Power Supply	24 VDC nominal, 18-32 VDC
Operating Temperature	-40°C to +65°C (-40°F to +149°F)
Material	Aluminum or Stainless Steel
Gas Types	Toxic, Oxygen, and Combustible gases
Output	4-20 mA
Relays	3 programmable relays
Approvals	ATEX, IECEx, UL, CSA
Sensor Compatibility	Electrochemical, catalytic, infrared, and other sensor types
