XNX Universal Transmitter

Section 6 - Specications

149

ATEX Protection

(Method, Protection Level, and Temperature)

Model Number

XNX-AM**-*****

SN Format

XXXXXX YY WW NNNN

Prod Code Year Week Unit

Supply Voltage and Power

Model Type Dependent

INMETRO approval

GOST approval

DEKRA EXAM

ATEX Certicate Number

Oxygen and Toxic Gas

Performance Certicate Number

Standard

Figure 231. XNX-AM**-***** Conguration
