Honeywell XNX Technical Manual

XNX Universal Transmitter
Appendix A - HART
®
Protocol
180
Main Menu Key Sub Menus
Online...
1DeviceSetup
2Concentration0.00
%LEL
3PVAlrmTyp
4MonitoringStateNormalMonitoring
5ResetAlarmFault(s)None
6GasNameMethane
7SensorTypeOptima
Device Setup...
1UserLogin
2XNXDisplay...
3DisplayMenu...
4TestMenu...
5Calibration...
6Configuration...
7DeviceStatus...
8DetailedSetup...
9Review
Display Menu...
1ResetAlarmFaults
2EventHistory
3DisplayBasicInfo...
4DisplaySWInfo...
5DisplayOpticalPerformance
6DisplaymASettings
7DisplayAlarmSettings
8DisplayMaintenanceStatus
9DisplayInstallationStatus
Display Installation Status...
1PowerSupplyVolt...19403
mVolt
2OperatingVoltage3297
mVolt
3SensorI/PVoltage0
mVolt
4SensorVoltage0
mVolt
5XNXTemp
33degC
6SensorTemp
41degC
7Loopcurrent
4.000mA
Online...
1DeviceSetup
2Concentration0.00
%LEL
3PVAlrmTyp
4MonitoringStateNormalMonitoring
5ResetAlarmFault(s)None
6GasNameMethane
7SensorTypeOptima
Device Setup...
1UserLogin
2XNXDisplay...
3DisplayMenu...
4TestMenu...
5Calibration...
6Configuration...
7DeviceStatus...
8DetailedSetup...
9Review
Test Menu...
1InhibitLong-term
2ForcemAO/P
3Alarm/FaultSimulation
XNX HART Basic Menus (cont’d)


Honeywell XNX Specifications

General

Ingress Protection	IP66/67
Product Type	Universal Transmitter
Enclosure Rating	IP66/67
Display	LCD
Communication Protocols	HART, Modbus, Foundation Fieldbus
Power Supply	24 VDC nominal, 18-32 VDC
Operating Temperature	-40°C to +65°C (-40°F to +149°F)
Material	Aluminum or Stainless Steel
Gas Types	Toxic, Oxygen, and Combustible gases
Output	4-20 mA
Relays	3 programmable relays
Approvals	ATEX, IECEx, UL, CSA
Sensor Compatibility	Electrochemical, catalytic, infrared, and other sensor types
