Honeywell XNX Technical Manual

XNX Universal Transmitter
Appendix A - HART
®
Protocol
182
Main Menu Key Sub Menus
Online...
1DeviceSetup
2Concentration0.00
%LEL
3PVAlrmTyp
4MonitoringStateNormalMonitoring
5ResetAlarmFault(s)None
6GasNameMethane
7SensorTypeOptima
Device Setup...
1UserLogin
2XNXDisplay...
3DisplayMenu...
4TestMenu...
5Calibration...
6Configuration...
7DeviceStatus...
8DetailedSetup...
9Review
Detailed Setup...
1OutputCondition...
2DeviceInformation...
Online...
1DeviceSetup
2Concentration0.00
%LEL
3PVAlrmTyp
4MonitoringStateNormalMonitoring
5ResetAlarmFault(s)None
6GasNameMethane
7SensorTypeOptima
Device Setup...
1UserLogin
2XNXDisplay...
3DisplayMenu...
4TestMenu...
5Calibration...
6Configuration...
7DeviceStatus...
8DetailedSetup...
9Review
Review
1ManufacturerHoneywell
2ModelXNX
3SensorTypeOptima
4PV%LEL
5InfoMinRange100.00%LEL
6InfoMaxRange100.00%LEL
7PV%Range0.000%
8PVXferfnctnLinear
9PV4.000mA
PVAlrmtypNone
TagS.TOWER
Longtag
   D e s c r i p t o r S O U T H  T O W E R
MessageCRACKINGTOWER
Finalasmblynum0
Devid1081234
Universalrev6
Flddevrev1
Softwarerev38
Polladdr0
LoopCurntModeEnabled
Cfgchngcount6
Numreqpreams9
Numresppreams7
XNX HART Basic Menus (cont’d)

Honeywell XNX Specifications

General

Ingress Protection	IP66/67
Product Type	Universal Transmitter
Enclosure Rating	IP66/67
Display	LCD
Communication Protocols	HART, Modbus, Foundation Fieldbus
Power Supply	24 VDC nominal, 18-32 VDC
Operating Temperature	-40°C to +65°C (-40°F to +149°F)
Material	Aluminum or Stainless Steel
Gas Types	Toxic, Oxygen, and Combustible gases
Output	4-20 mA
Relays	3 programmable relays
Approvals	ATEX, IECEx, UL, CSA
Sensor Compatibility	Electrochemical, catalytic, infrared, and other sensor types
