Honeywell XNX Technical Manual

XNX Universal Transmitter
Section 1 - Introduction
26
CongurationMode

SelectLanguage

SetDate&Time
  SetDateFormat
  SetYear,Month,Day
  SetHours,Minutes,Seconds

SensorTypeSelection
  SetmVSensorType
10
  SetmASensorType
11
 GasSelection
  ChangingtheGasorUnitsName
 GasSelectionsandAlarmLimitsBasedonmV 
   SensorType

Range&Alarms
  SetRange
  Alarm1Type
  Alarm1Setpoint
  Alarm1LatchingorNon-latching
  Alarm2Type
  Alarm2Setpoint
  Alarm2LatchingorNon-latching
  SelectingtheNumericFormat

Latching/Non-latching

ChangeMeas�Units
12
 mAOutputLevels
  ChangemAforInhibit
10Catalyticbeadsensoronly
11SearchpointOptimaandSearchlineExcelonly
12ECCandmVonly
  ChangemAforWarning
  ChangemAforOverrange
  ChangemAforLowSignal
  ChangemAforBlockedBeam

SetCalibrationInterval

AcceptNewSensorType
13
  Informationscreenidentifyingprevioussensorand
   newsensor
  Screendisplaysnewtypeandoldtype

SetBeamBlock
14
  SelectBeamBlockThreshold
  SelectTimetoBeamBlock
  SelectTimetoFault

SetPathLength
15
  SetNewPathLength

CongureUnitID
  EditID
  ClearID
  DefaultID

RelayOptions
16
  SelectA1
  SelectA2

FieldbusOptions
17
  ChangeFieldbusAddress
  ChangeFieldbusSpeed

Security
  ResetandLVL1
  LVL1Code
  LVL2Code
13Electrochemicalandcatalyticbeadsensorsonly
14SearchlineExcelonly
15SearchlineExcelonly
16Optionalrelayonly
17OptionalFoundationFieldbusandModbusonly

Honeywell XNX Specifications

General

Ingress Protection	IP66/67
Product Type	Universal Transmitter
Enclosure Rating	IP66/67
Display	LCD
Communication Protocols	HART, Modbus, Foundation Fieldbus
Power Supply	24 VDC nominal, 18-32 VDC
Operating Temperature	-40°C to +65°C (-40°F to +149°F)
Material	Aluminum or Stainless Steel
Gas Types	Toxic, Oxygen, and Combustible gases
Output	4-20 mA
Relays	3 programmable relays
Approvals	ATEX, IECEx, UL, CSA
Sensor Compatibility	Electrochemical, catalytic, infrared, and other sensor types
