Section 2 - Installation and Operation
29
Warning: Whenthetransmitterisequippedwiththeoptional
RemoteMountKit,theremotesensormustbesecurelymountedin
afixedposition.TheRemoteSensorkitisnotintendedtobeusedas
ahand-heldsensor.
Thetransmitterisconguredwithvecable/conduitportsbuilt
intothehousingforwiringandmountingsensors�Figure25
providestheguidelinestoproperinstallationoftheXNX�
Whilerelaywiringcanuseany
availablecable/conduitportin
theXNXenclosure,donotuse
thesamecable/conduitportfor
bothrelayresetandrelaysignal
linestoavoidelectricalnoise�
Option Position
LocalHART
®
Option B
XNXElectrochemicalSensor-Local/Remote C
MPD,705Series,SensepointSeries C
SearchpointOptimaPlus AorE
SearchlineExcel TypicallyC
RemoteSensorConnection(exceptEC) Anyremaining
SearchpointOptimaPlus-Remote Anyremaining
Modbus Anyremaining
Relays Anyremaining
Power Anyremaining
Figure 25. XNX Universal Transmitter cable/conduit port assignments
Integral Mounting Lugs

Figure 26. XNX Universal Transmitter mounting lugs

Figure 27. Optional pipe and ceiling mounts
