Honeywell XNX - Page 65

XNX Universal Transmitter
Section 2 - Installation and Operation
63
MPD-CB1 (100% LEL)
Hydrogen
Methane-1 Methane-2
Methanol
Ethelyne-1 Ethelyne-2
Ethanol-1 Ethanol-2
Propane-1 Propane-2
Butane-1 Butane-2
Hexane-1 Hexane-2
Star 1 Star 2 Star 3 Star 4 Star 5 Star 6 Star 7 Star 8
Lower Alarm
Limit (% LEL)
10 10 10 10 10 10 10 10 10 10 10 10 10 10 20 20 20 10 10 10 10 10
Upper Alarm
Limit (% LEL)
60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60
% Volume
Reference
4.0 5.0 4.4 5.5 2.7 2.3 3.3 3.1 2.0 1.7 1.5 1.4 1.2 1.0 n/a n/a n/a n/a n/a n/a n/a n/a
705-STD (100% LEL)
Hydrogen
Methane-1 Methane-2
Methanol
Ethelyne-1 Ethelyne-2
Ethanol-1 Ethanol-2
Propane-1 Propane-2
Butane-1 Butane-2
Hexane-1 Hexane-2
Star 1 Star 2 Star 3 Star 4 Star 5 Star 6 Star 7 Star 8
Lower Alarm
Limit (% LEL)
20 20 20 25 25 30 30 30 25 30 30 30 50 50 50 30 25 20 20 20 15 15
Upper Alarm
Limit (% LEL)
60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60 60
% Volume
Reference
4.0 5.0 4.4 5.5 2.7 2.3 3.3 3.1 2.0 1.7 1.5 1.4 1.2 1.0 n/a n/a n/a n/a n/a n/a n/a n/a

