Item Description
14 Fan connector 7
15 GPU power connector
16 Fan connector 6
17 x4 SATA port 2
18 Fan connector 5
19 TPM connector
20 x1 SATA port 2
21 Fan connector 4
22 SATA management port
23 x1 SATA port 1
24 Fan connector 3
25 x4 SATA port 1
26 Fan connector 2
27 Fan connector 1
28 Drive backplane power connector
29 NVMe connector port 3A
30 NVMe connector port 2A
31 NVMe connector port 1A
32 Power connector for Standard or Flex Slot power supply
33 Power connector for Flex Slot power supply
34 Energy pack connector
35 Sideband connector for Flex Slot power supply
36 Chassis intrusion detection switch connector
37 Chassis intrusion detection switch (optional)
38 Smart Array modular controller connector
2
39 Secondary PCIe riser connector
40 Serial port connector
1
If the memory card connected to the microSD slot is not visible in Windows Device Manager, in the menu bar, click View > Show hidden
device.
2
This connector is not available if the expansion board is installed in the secondary riser slot 3.
Component identification 120
