HP StorageWorks MSA1000 User Manual

Installation Procedures - for all MSA1000 Deployments
29MSA1000 Installation Guide
Step 6: Installing Option Kits in your MSA1000
If your plans include adding any of the available option kits for the MSA1000
(such as a redundant controller, additional controller cache, or embedded
interconnect device), install them now.
It is easier to install these options now, before you install the MSA1000 in
the rack.
Some of the MSA1000 option kits include:
■ Redundant controller
■ Additional controller cache
■ Redundant Fibre Channel I/O Module
■ Embedded MSA SAN Switch 2/8
■ Embedded MSA Hub 2/3
Caution: Do not install hard drives in the MSA1000 until after the MSA1000
is mounted in the rack.
■ Installed drives will make the MSA1000 too heavy to safely lift and install
in the rack.
■ If the hard drives are installed prior to racking the MSA1000, the
vibrations caused while moving the MSA1000 may damage the hard
drives and void their warranty.
Figure 2: Installing an MSA SAN Switch 2/8 in the MSA1000

HP StorageWorks MSA1000 Specifications

General

RAID levels	0, 1, 0+1, 5
Certification	Microsoft Cluster Server Certification\\r Hewlett Packard Data Protector\\r VERITAS Backup Exec and NetBackup\\r Legato NetWorker for Windows\\r Computer Associates BrightStor Enterprise Backup
Internal memory	256 MB
Memory clock speed	- MHz
Internal memory type	-
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Supported storage drive interfaces	SCSI
Windows operating systems supported	Yes
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	52.1 mm
Width	48.3 mm
Height	17.5 mm
Weight	31210 g
