Installation Procedures - for all MSA1000 Deployments
53MSA1000 Installation Guide
To Determine Which Version of the MSA1000 Controller Firmware to Use
To determine if you can use the MSA1000 Controller firmware that was
preinstalled on your MSA1000 Controller or if you need to download and install a
newer or alternative version from the Web:
1. With your MSA1000 powered-on, use the arrow buttons on the front of the
MSA1000 Controller to scroll through the messages until the following
message is displayed:
00 Array controller Firmware ver <version>
2. Record the version of the controller firmware on your MSA1000 in “My
MSA1000 Worksheets” on page 97 of this guide.
3. Go to the Software, Firmware & Drivers page of the MSA1000 website at
http://www.hp.com/go/msa1000 .
4. Under the Controller Firmware banner, select the entry for your server type
or operating system.
5. Read the screen display for the Web-version of the controller firmware and
record the Web-version of the firmware in “My MSA1000 Worksheets” on
page 97 of this guide.
6. If the Web-version of the controller firmware is a higher number than the
version provided with your MSA1000, follow the instructions provided on the
MSA1000 website to download and install this newer version of firmware on
your MSA1000.

HP StorageWorks MSA1000 Specifications

General

RAID levels	0, 1, 0+1, 5
Certification	Microsoft Cluster Server Certification\\r Hewlett Packard Data Protector\\r VERITAS Backup Exec and NetBackup\\r Legato NetWorker for Windows\\r Computer Associates BrightStor Enterprise Backup
Internal memory	256 MB
Memory clock speed	- MHz
Internal memory type	-
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Supported storage drive interfaces	SCSI
Windows operating systems supported	Yes
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	52.1 mm
Width	48.3 mm
Height	17.5 mm
Weight	31210 g
