50 MSA1000 Installation Guide
If the MSA1000 Startup Complete message is not displayed, check your cable
connections to the MSA1000, check the availability of your power source, and
review the setup instructions in the previous sections of this guide.
For complete information about the MSA1000 Controller and its display
messages, see the HP StorageWorks MSA1000 Controller User Guide, included
on the MSA1000 Support Documentation CD, and available on the Technical
Documents page of the MSA1000 website at
http://www.hp.com/go/msa1000 .
Verify the operating status of the interconnect devices
To verify that your interconnect device is operating properly, view the patterns of
the status lights on your switch or hub and compare them with the patterns
described in the literature for these devices.
Verify the operating status of the server(s)
Although the server cannot yet “see” your MSA1000, verify that the server is
operating properly. A simple test is to verify that your operating system loaded
and then open one of its software applications or your Web browser.
If your server is not operating properly, refer to the manuals that came with the
server for help.

HP StorageWorks MSA1000 Specifications

General

RAID levels	0, 1, 0+1, 5
Certification	Microsoft Cluster Server Certification\\r Hewlett Packard Data Protector\\r VERITAS Backup Exec and NetBackup\\r Legato NetWorker for Windows\\r Computer Associates BrightStor Enterprise Backup
Internal memory	256 MB
Memory clock speed	- MHz
Internal memory type	-
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Supported storage drive interfaces	SCSI
Windows operating systems supported	Yes
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	52.1 mm
Width	48.3 mm
Height	17.5 mm
Weight	31210 g
