49MSA1000 Installation Guide
5. Power on the external interconnect devices.
6. Power on the servers in the SAN with access to the MSA1000.
7. After you have powered up your MSA1000 and the SAN, examine your
MSA1000, the interconnect devices, and the server and verify that each
component is operating properly.
Verify the operating status of the MSA1000
Each MSA1000 Controller contains an integrated LCD display module. This
module displays informational and error messages, shows the current status of the
MSA1000, and provides an interface for user input.
To verify that your MSA1000 is operating properly, use the arrow buttons on the
front of the LCD panel on the MSA1000 and look for the following messages:
Note: Record the information displayed on the MSA1000 LCD panel in “My
MSA1000 Worksheets” on page 97.
Table 3: MSA1000 Startup Messages
Message Meaning
01 MSA1000 Startup Complete
The array controller has completed its
power on sequence and is operational.
SAN Switch 2/8 <IP Address>
If an MSA SAN Switch 2/8 is installed
in the MSA1000, this message will be
displayed after the power-on self-test for
the switch is completed.
516 Fibre Sub-System Link
Failure
There is no active fibre connection to the
MSA1000 array controller.
This message is expected, because,
although we have physically installed
the HBA in the server, we have not yet
installed the drivers for the HBA and the
MSA1000.
You may safely ignore this message.
00 Array controller Firmware
ver <version>
The current version of the firmware
running on the MSA1000 controller.

HP StorageWorks MSA1000 Specifications

General

RAID levels	0, 1, 0+1, 5
Certification	Microsoft Cluster Server Certification\\r Hewlett Packard Data Protector\\r VERITAS Backup Exec and NetBackup\\r Legato NetWorker for Windows\\r Computer Associates BrightStor Enterprise Backup
Internal memory	256 MB
Memory clock speed	- MHz
Internal memory type	-
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Supported storage drive interfaces	SCSI
Windows operating systems supported	Yes
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	52.1 mm
Width	48.3 mm
Height	17.5 mm
Weight	31210 g
