HP StorageWorks MSA1000 User Manual

Installation Procedures - for all MSA1000 Deployments
39MSA1000 Installation Guide
Install the Hard Drives in the MSA1000
Now that the MSA1000 and any additional storage enclosures are installed and
secured in the rack, you can install your hard drives into the drive bays.
For a list of the hard drives that are supported for use on the MSA1000, review the
MSA1000 Compatibility Guide, located on the MSA1000 Technical Documents
Web page at
http://www.hp.com/go/msa1000 .
Caution: Follow industry-standard practices when handling hard drives.
To install the hard drives:
1. Remove the hard drive blank from the front of the MSA1000.
Press both of the ejector buttons 1 and slide the blank out of the drive bay 2.
Figure 11: Removing hard drive blanks
2
1
2

HP StorageWorks MSA1000 Specifications

General

RAID levels	0, 1, 0+1, 5
Certification	Microsoft Cluster Server Certification\\r Hewlett Packard Data Protector\\r VERITAS Backup Exec and NetBackup\\r Legato NetWorker for Windows\\r Computer Associates BrightStor Enterprise Backup
Internal memory	256 MB
Memory clock speed	- MHz
Internal memory type	-
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Supported storage drive interfaces	SCSI
Windows operating systems supported	Yes
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	52.1 mm
Width	48.3 mm
Height	17.5 mm
Weight	31210 g
