HP StorageWorks MSA1000 User Manual

Installation Procedures - for all MSA1000 Deployments
42 MSA1000 Installation Guide
Connect the SCSI Cables (if needed)
If you have purchased and installed additional storage enclosures for the
MSA1000, use standard VHDCI SCSI cables to connect the MSA1000 to the
enclosures.
SCSI cables are included in the shipping carton with the storage enclosures.
Note: Tighten the thumbsrews on the SCSI cables to ensure a secure connection.
Figure 14: SCSI cable connections to an HP StorageWorks 4314 storage enclosure

HP StorageWorks MSA1000 Specifications

General

RAID levels	0, 1, 0+1, 5
Certification	Microsoft Cluster Server Certification\\r Hewlett Packard Data Protector\\r VERITAS Backup Exec and NetBackup\\r Legato NetWorker for Windows\\r Computer Associates BrightStor Enterprise Backup
Internal memory	256 MB
Memory clock speed	- MHz
Internal memory type	-
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Supported storage drive interfaces	SCSI
Windows operating systems supported	Yes
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	52.1 mm
Width	48.3 mm
Height	17.5 mm
Weight	31210 g
