HP StorageWorks MSA1000 User Manual

Configuration Procedures - for OpenVMS Environments
74 MSA1000 Installation Guide
Obtaining the Current Fibre SCSI ECO Kit
The Fibre SCSI ECO kits needed for OpenVMS are the following (or later)
versions:
— OpenVMS 7.3-1DEC-AXPVMS-VMS731_FIBRE_SCSI-V0200-4
— OpenVMS 7.3 DEC-AXPVMS-VMS73_FIBRE_SCSI-V0500-4
— OpenVMS 7.2-2 DEC-AXPVMS-VMS722_FIBRE_SCSI-V0300-4
Download the kit from the Software Patches website at
http://ftp.support.compaq.com/patches/.new/openvms.shtml.
Obtaining the MSA1000 Firmware
To obtain the firmware file, do one of the following:
■ Go to the Software, Firmware & Drivers page of the MSA1000 website at
http://www.hp.com/go/msa1000
Copy the most recent MSA1000 firmware file to a disk directory on a system
with access to the MSA1000.
■ Mount the CD-ROM drive using the following command:
MOUNT/OVER=ID <ddcn:>/UNDEFINED_FAT=STREAM_LF:326767
where <ddcn:> is the device name of the CD-ROM drive on the OpenVMS
system. For example:
DQA0: or DKA400:.
Copy the most recent MSA1000 firmware file to a disk directory on a system
with access to the MSA1000.
Note: The firmware file must be copied to a local disk before it can be flashed. When
the MSA_UTIL program reads the firmware image from the CD-ROM, it exits with an
error access violation.

HP StorageWorks MSA1000 Specifications

General

RAID levels	0, 1, 0+1, 5
Certification	Microsoft Cluster Server Certification\\r Hewlett Packard Data Protector\\r VERITAS Backup Exec and NetBackup\\r Legato NetWorker for Windows\\r Computer Associates BrightStor Enterprise Backup
Internal memory	256 MB
Memory clock speed	- MHz
Internal memory type	-
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Supported storage drive interfaces	SCSI
Windows operating systems supported	Yes
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	52.1 mm
Width	48.3 mm
Height	17.5 mm
Weight	31210 g
