HP StorageWorks MSA1000 User Manual

Configuration Procedures - for Windows Environments
59MSA1000 Installation Guide
Installing the ACU on your Windows Management Server
If you plan to use the ACU to configure the MSA1000, perform the following
steps to install it on the server that you have designated for management tasks:
1. Insert the MSA1000 Support Software CD into the CD-ROM drive of your
management server and let it auto-start the installation program.
2. Agree to the license agreement.
3. Click Install Array Configuration Utility.
4. Click Install and follow the onscreen instructions to complete the installation.
After the files have been copied, a completion message is displayed.
5. Click Exit and remove the MSA1000 Support Software CD from the
CD-ROM drive.
6. From the desktop, click Start > Programs > Compaq System Tools >hp
Array Configuration Utility > Set up hp Array Configuration Utility.
The browser-based Management Setup Wizard is opened.
7. Click Next and follow the on-screen instructions to set:
■ Administrator, Operator, and User passwords
■ Device Trust Mode
■ Remote Access
■ Execution Mode
Note: The ACU runs in the background. Its icon is displayed in the system tray.
To launch the ACU and use it to configure your storage, see the
HP Array Configuration
Utility User Guide
. This guide is available on the MSA1000 Support Documentation
CD and the ACU website at
http://h18000.www1.hp.com/products/servers/proliant
storage/software-management/acumatrix/index.html.

HP StorageWorks MSA1000 Specifications

General

RAID levels	0, 1, 0+1, 5
Certification	Microsoft Cluster Server Certification\\r Hewlett Packard Data Protector\\r VERITAS Backup Exec and NetBackup\\r Legato NetWorker for Windows\\r Computer Associates BrightStor Enterprise Backup
Internal memory	256 MB
Memory clock speed	- MHz
Internal memory type	-
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Supported storage drive interfaces	SCSI
Windows operating systems supported	Yes
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	52.1 mm
Width	48.3 mm
Height	17.5 mm
Weight	31210 g
