HP StorageWorks MSA1000 User Manual

Configuration Procedures - for Tru64 UNIX Environments
83MSA1000 Installation Guide
Obtaining the Node ID of the MSA1000
1. Access the CLI of the MSA1000.
Use the MSA1000 CLI configuration cable (part number 259992-001) to
connect the MSA1000 to a laptop, personal computer, or AlphaServer
console.
See the HP StorageWorks Modular Smart Array 1000 Command Line
Interface User Guide for instructions.
(To connect the AlphaServer console to the MSA1000, use the tip
command, as identified in the tip(1) reference pages.)
2. Execute the following command to view controller information:
show this_controller
Controller:
MSA1000(c) Compaq P56350B9IMX00T
Software 2.38 Build 122 Hardware 7
Controller Identifier: V3C0
NODE_ID = 500805F3-0001BA20
Note: Do not abbreviate MSA1000 commands.
3. Record the MSA1000 Node ID in the provided spaces below.
This information will be used later in the upgrade procedure.
MSA1000 Node_ID _________________________
Directory/firmware filename _________________________
Possible MSA1000 _________________________
Bus/Target/LUN values _________________________

HP StorageWorks MSA1000 Specifications

General

RAID levels	0, 1, 0+1, 5
Certification	Microsoft Cluster Server Certification\\r Hewlett Packard Data Protector\\r VERITAS Backup Exec and NetBackup\\r Legato NetWorker for Windows\\r Computer Associates BrightStor Enterprise Backup
Internal memory	256 MB
Memory clock speed	- MHz
Internal memory type	-
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Supported storage drive interfaces	SCSI
Windows operating systems supported	Yes
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	52.1 mm
Width	48.3 mm
Height	17.5 mm
Weight	31210 g
