HP StorageWorks MSA1000 User Manual

Configuration Procedures - for Tru64 UNIX Environments
82 MSA1000 Installation Guide
Obtaining the MSA1000 Firmware
To obtain the firmware file:
Note: The firmware filename varies depending on the version number.
1. From Tru64 UNIX, log in as the root user and create a directory for the
MSA1000 firmware:
# mkdir /msa1000
2. Obtain the MSA1000 firmware file by doing one of the following:
■ Go to the Software, Firmware & Drivers page of the MSA1000 website at
http://www.hp.com/go/msa1000
Copy the most recent MSA1000 firmware file to the MSA1000 directory.
Record the firmware file name with the directory in the System
Information Table to complete the pathname.
■ Mount the CD-ROM drive and copy the firmware to the /MSA1000
directory:
MOUNT/OVER=ID <ddcn:>/UNDEFINED_FAT=STREAM_LF:326767
where <ddcn:> is the device name of the CD-ROM on the OpenVMS
system. For example:
DQA0: or DKA400:.
Copy the most recent MSA1000 firmware file to a disk directory on a
system with access to the MSA1000.
# mount -rt cdfs /dev/disk/cdrom0c /mnt
# cp /mnt/<CD-ROM directory>/v3<xxxxx>.bin
/msa1000/v3<xxxxx>.bin
Record the firmware file name with the directory in the System
Information Table to complete the pathname.

HP StorageWorks MSA1000 Specifications

General

RAID levels	0, 1, 0+1, 5
Certification	Microsoft Cluster Server Certification\\r Hewlett Packard Data Protector\\r VERITAS Backup Exec and NetBackup\\r Legato NetWorker for Windows\\r Computer Associates BrightStor Enterprise Backup
Internal memory	256 MB
Memory clock speed	- MHz
Internal memory type	-
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Supported storage drive interfaces	SCSI
Windows operating systems supported	Yes
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	52.1 mm
Width	48.3 mm
Height	17.5 mm
Weight	31210 g
