HP StorageWorks MSA1000 User Manual

Configuration Procedures - for Linux Environments
65MSA1000 Installation Guide
6. Install the FCA2214 HBA driver on the new kernel by entering:
rpm -Uvh rmp filename
where rpm filename is the name of the rpm file for your distribution of
Linux.
After a few minutes, the following messages are displayed:
Attempting to load qla2200 ..... FAILED
Attempting to load qla2300 ..... OK
7. For Red Hat Linux Advanced Server/Enterprise Server, run the provided
script to modify the SCSI blacklist.
a. Navigate to the
/opt/hp/storage_drivers/qla604/utils directory.
b. Enter the command scripname
edit_initrd.redhat.
c. Follow the on-screen instructions to complete the update.
8. Remove the MSA1000 Support Software CD from the CD-ROM drive and
reboot your server.
9. Repeat these procedures for each Linux server that will access the MSA1000.
10. Connect the MSA1000 to the SAN, if it is not already connected.
Compiling a Driver from Source Code
If you need to build your own FCA2214 HBA driver module from source code or
manually patch the Linux kernel, refer to InstallNotes.txt in the /LINUX directory
on the MSA1000 Support Software CD.

HP StorageWorks MSA1000 Specifications

General

RAID levels	0, 1, 0+1, 5
Certification	Microsoft Cluster Server Certification\\r Hewlett Packard Data Protector\\r VERITAS Backup Exec and NetBackup\\r Legato NetWorker for Windows\\r Computer Associates BrightStor Enterprise Backup
Internal memory	256 MB
Memory clock speed	- MHz
Internal memory type	-
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Supported storage drive interfaces	SCSI
Windows operating systems supported	Yes
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	52.1 mm
Width	48.3 mm
Height	17.5 mm
Weight	31210 g
