Item Component Description
3 Power jack Connects the power cord.
4 Expansion slot 2, PCIe3 ×4 (1) For additional hardware capabilities, install a compatible
low‑profile PCIe expansion board here. This expansion slot
supports expansion boards with a physical connector link
widths of up to ×16.
1
5 Expansion slot 1, PCIe3 ×8 (8, 4, 1) For additional hardware capabilities, install a compatible
low‑profile PCIe expansion board here. This expansion slot
supports expansion boards with a physical connector link
widths of up to ×16.
1
6 Video port
Connects to an analog VGA monitor or projector.
7 Display port 1 Connects to a digital display device, such as a high-resolution
set top boxes or TV displays.
2
8 Display port 2 Connects to a digital display device, such as a high-resolution
set top boxes or TV displays.
2
9 USB 2.0 ports (2)
Connect USB 2.0 devices to these ports.
10 USB 3.0 ports (2)
Connect USB 3.0 devices to these ports. USB 3.0 support
after POST varies by operating system.
11 NIC port 1 (1 Gb) Connect an Ethernet cable here to connect the server to a
wired network.
3
12 NIC port 2 (1 Gb) Connect an Ethernet cable here to connect the server to a
wired network.
3
1
This expansion slot is open-ended, which enables down-plugging. Down-plugging means a larger-width expansion board
can be installed in a smaller-width connector. For this server, the expansion slot supports low-profile expansion boards
with a physical connector link width of up to ×16. The board operates at the highest common negotiable link width
specified for the slot.
2
To support 4K resolution at a full 60 Hz frame rate, this Display port requires dual-channel memory configuration. Single-
channel memory configuration will only support up to 30 Hz frame rate.
3
This NIC port supports 10/100/1000 Mbps data transfer rate per port.
12 Component identification
