7. After five seconds, remove the jumper from pins 1 and 2, and move it back to the default position on pins

2 and 3.

8. Install the system board assembly on page 20.

9. Install the chassis cover on page 20.

10. Connect all peripheral cables to the server.

11. Connect the power cord to the server power jack, and then to the AC source.

12. Power up the server on page 16.

Embedded UEFI Shell

The system BIOS in this server includes an Embedded UEFI Shell in the ROM. The UEFI Shell environment

provides an API, a command-line prompt, and a set of CLIs that allow scripting, file manipulation, and system

information. These features enhance the capabilities of the Aptio Setup Utility.

For more information, see the UEFI Shell Specification on the UEFI website:

http://www.uefi.org/specifications

Embedded UEFI Shell 57

Questions and Answers:

Need help?

Do you have a question about the HPE ProLiant MicroServer Gen10 Series and is the answer not in the manual?

HPE ProLiant MicroServer Gen10 Series Specifications

General

Product Line	HPE ProLiant MicroServer
Processor	AMD Opteron X3000 Series
Memory Slots	2
Networking	2x 1GbE ports
Memory	Up to 32 GB DDR4 UDIMM
Storage	4 LFF SATA HDD bays (3.5-inch)
RAID Support	RAID 0, 1
Power Supply	200W non-redundant power supply
Management	HPE iLO 5 Standard
Form Factor	Micro Tower
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Weight	Approx. 6.5 kg
