hpmont HD30 Series User Manual

Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―148― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
models:
60.0s
F03.09
Switching frequency of
acceleration time 2 and
time 1
0.00－upper limit 0.00Hz 0.01Hz ×
F03.10
Switching frequency of
deceleration time 2 and
time 1
0.00－upper limit 0.00Hz 0.01Hz ×
F03.11
S-curve characteristic
time at starting
acceleration
0.00－2.50s 0.20s 0.01s ○
F03.12
S-curve characteristic
time at ending
acceleration
0.00－2.50s 0.20s 0.01s ○
F03.13
S-curve characteristic
time at starting
deceleration
0.00－2.50s 0.20s 0.01s ○
F03.14
S-curve characteristic
time at ending
deceleration
0.00－2.50s 0.20s 0.01s ○
F03.15
Acceleration time of jog
operation
0.1－6000.0s 6.0s 0.1s ○
F03.16
Deceleration time of
jog operation
0.1－6000.0s 6.0s 0.1s ○
F03.17
Deceleration time of
emergency stop
0.1－6000.0s 10.0s 0.1s ○
Group F04 Process PID Control (refer to pages 70
－
72)
F04.00
Process PID control
selection
0: PID control is disabled
1: PID control is enabled
0 1 ×
F04.01
Reference source
selection
0: Digital reference
1: AI analogue reference
2: Terminal pulse reference
0 1 ×
F04.02
Feedback source
selection
0: AI analogue feedback
1: Terminal pulse feedback
0 1 ×
F04.03
Setting digital
reference
-10.00－10.00V 0.00V 0.01V ○
F04.04 Proportional gain (P) 0.00－10.00 2.00 0.01 ○
F04.05 Integral time (I) 0.00－10.00s 1.00s 0.01s ○
F04.06 Integral upper limit 0.00－upper limit 50.00Hz 0.01Hz ○
F04.07 Differential time (D)
0.00－10.00s
The differential is disabled
when F04.07 is set to 0
0.00s 0.01s ○
F04.08
Differential amplitude
limit value
0.00－upper limit 20.00Hz 0.01Hz ○
F04.09 Sampling cycle (T) 0.01－50.00s 0.10s 0.01s ○
