hpmont HD30 Series User Manual

Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD30 Series Inverters User Manual －147－
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
current for speed
search
current)
F02.09
Acc./Dec. time of the
speed search
1.0－50.0s 5.0s 0.1s ×
F02.10
Waiting time of speed
search
0.1－5.0s 1.0s 0.1s ×
F02.11
V/f ratio of speed
search
0.0－100.0% 100.0% 0.1% ×
F02.12
Disposal time after
speed search
0.01－5.00s 1.00s 0.01s ×
F02.13 Stop mode selection
0: Decelerate to stop
(decreases to DWELL
frequency setting and holds
on retention time of DWELL
frequency, then it will stop)
1: Coast to stop
2: Decelerate to stop with DC
braking
0 1 ×
F02.14
DWELL frequency
setting at stop
0.00－upper limit 0.00Hz 0.01Hz ×
F02.15
Retention time of
DWELL frequency at
stop
0.00－10.00s 0.00s 0.01s ×
F02.16
DC braking initial
frequency at stop
0.00－50.00Hz 0.50Hz 0.01Hz ×
F02.17
DC braking waiting
time at stop
0.00－10.00s 0.00s 0.01s ×
F02.18 DC braking time at stop 0.00－10.00s 0.50s 0.01s ×
F02.19 Jog control mode
0: The jog functions of start
and stop mode etc are
invalid.
1: The jog functions of start
and stop mode etc are
enabled.
0 1 ×
Group F03 Acceleration/Deceleration Parameters (refer to pages 68
－
70)
F03.00
Acc./Dec. mode
selection
0: Linear Acc. or Dec.
1: S-curve Acc. or Dec.
0 1 ○
F03.01 Acceleration time 1 0.1－6000.0s
15kW or
below
models:
10.0s
18.5－55
kW: 30.0s
other
0.1s ○
F03.02 Deceleration time 1 0.1－6000.0s 0.1s ○
F03.03 Acceleration time 2 0.1－6000.0s 0.1s ○
F03.04 Deceleration time 2 0.1－6000.0s 0.1s ○
F03.05 Acceleration time 3 0.1－6000.0s 0.1s ○
F03.06 Deceleration time 3 0.1－6000.0s 0.1s ○
F03.07 Acceleration time 4 0.1－6000.0s 0.1s ○
F03.08 Deceleration time 4 0.1－6000.0s 0.1s ○
