hpmont HD30 Series User Manual

Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―168― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
F18.00 Language selection
0: Chinese
1: English
0 1 ○
F18.01
Displaying contrast of
the LCD display panel
1－10 5 1 ○
F18.02
Set the display
parameter 1 during
operation
0: Reserved
1: Inverter’s rated current
2: Inverter’s extension
function
3: Inverter status
4: Master setting frequency
source
5: Master setting frequency
6: Auxiliary setting frequency
7: Setting frequency
8: Reference frequency (after
acceleration/ deceleration)
9: Output frequency
10: Setting speed
11: Running speed
12: Three-phase power
supply input phase sequence
13: Output voltage
14: Output current
15: Reserved
16: Output torque
17: Output power
18: DC bus voltage
19: Potentiometer input
voltage
20: AI1 input voltage
21: AI1 input voltage (after
disposal)
22: AI2 input voltage
23: AI2 input voltage (after
disposal)
24: AI3 input voltage
25: AI3 input voltage (after
disposal)
26: AI4 input voltage
27: AI4 input voltage (after
disposal)
28: DI6 terminal pulse input
frequency
29: AO1 output
30: AO2 output
31: High-speed output pulse
8 1 ○
F18.03
Set the display
parameter 2 during
operation
7 1 ○
F18.04
Set the display
parameter 3 during
operation
9 1 ○
F18.05
Set the display
parameter 4 during
operation
13 1 ○
F18.06
Set the display
parameter 5 during
operation
14 1 ○
F18.07
Set the display
parameter 6 during
operation
18 1 ○
F18.08
Set the display
parameter 1 at stop
7 1 ○
F18.09
Set the display
parameter 2 at stop
18 1 ○
