hpmont HD30 Series User Manual

Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―172― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
and in constant speed
running proces
F19.21
Auto current limiting
threshold
20.0－200.0%
G：150.0%
P：110.0%
0.1% ×
F19.22
Deceleration time at
auto current limiting
0.0－6000.0s
0.00: Limit current without
deceleration.
15kW and
below:
10.0s
18.5－55
kW inverter:
30.0s
75kW and
above:
60.0s
0.1s ×
F19.23
Enabled mode of
terminal run command
0: Rise edge enabled mode
1: Level enabled mode
0 1 ○
F19.24
Action voltage of
braking unit
220V inverter: 330－400V 380V
1V × 380V inverter: 630－750V 720V
660V inverter: 850－1200 1130V
F19.25 Reserved
F19.26 Preset length 0－65535m 0m 1m ×
F19.27 Actual length 0－65535m 0m 1m *
F19.28 Length ratio 0.001－30.000 1.000 0.001 ×
F19.29
Length checking
coefficient
0.001－1.000 1.000 0.001 ×
F19.30
Measuring shaft
diameter
1.00－100.00cm 10.00cm 0.01cm ×
F19.31
Number of pulses per
revolution
1－9999 1 1 ×
F19.32
Length arrive and
output function
selection
0: Output level signal
1: Output 500ms pulse
0 1 ○
F19.33
Record of length
disposal after length
arrive
0: Auto-clear
1: No change
0 1 ○
F19.34
Record of length
disposal at stop
0: Auto-clear
1: No change
0 1 ○
F19.35 Reserved
F19.36 Reserved
F19.37 Reserved
F19.38 Reserved
Group F20 Protection of Fault Parameters (refer to pages 116
－
119)
F20.00
Overload pre-alarm
detection
Units: Overload pre-alarm
detection
0: It is active all the time in
00000 1 ×
