Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―174― HD30 Series Inverters User Manual
No. Name Range
Factory
Default
Unit
Modified
attributes
Setting
3: It is detecting all the time
in running process, and then
cut off the output after
detecting (fault)
4: It is detectes only at the
same speed, and then cut off
the output after detecting
(fault)
F20.04
Inverter output
load-loss detection
threshold
0－100% 30% 1% ×
F20.05
Inverter output
load-loss detection
time
0.00－20.00s 1.00s 0.01s ×
F20.06
Motor overheating
signal input type
0: Does not detect the motor
overheating.
1: Positive charateristic
(PTC)
2: Negative charateristic
(NTC)
0 1 ×
F20.07
Thermistor value at
motor overheating
0.0－10.0kΩ 5.0kΩ 0.1kΩ ×
F20.08
Input phase loss
detection reference
0－50% 30% 1% ×
F20.09
Input phase loss
detection time
1.00－5.00s 1.00s 0.01s ×
F20.10
Output phase loss
detection reference
0－50% 20% 1% ×
F20.11
Output phase loss
detection time
0.00－20.00s 3.00s 0.01s ×
F20.12
PID reference lose
detected value
0－100%
0: Does not detect PID
reference lose
0% 1% ×
F20.13
PID reference loss
detection time
0.00－10.00s
When set to 0, does not
detect PID reference loss
0.20s 0.01s ×
F20.14
PID feedback loss
detected value
0－100%
0: Does not detect PID
feedback loss
0% 1% ×
F20.15
PID feedback loss
detection time
0.00－10.00s
When set to 0, does not
detect PID feedback loss
0.20s 0.01s ×
F20.16
Detection value at PID
feedback out of the
limit
0－100%
100%: Does not detect PID
feedback out of the limit
100% 1% ×
F20.17
Detection time at PID
0.00－10.00s 0.20s 0.01s ×
