Appendix A Parameter
MONT20 User Manual V1.6 61
Ref. Code
Function Setting Range Default
Attribute
Setting
11: Restore customized speed control
parameter 2 of customer Asyn. motor
12 - 30: Unused
F00.02 OD/CD mode selection
0: Speed control (with 4 switches)
1: Distance control (with encoder)
0
×
F00.03 Run command selection
0: Keypad (manual)
1: Terminal (automatic)
2: Demo loop running
3: Factory debugging mode
4: CAN communication
0
×
F00.04 Max. output frequency 1.00 - 99.99Hz 50.00Hz
×
F00.05 Running curve selection
0: Line
1: S curve
0
×
F00.06 Control selection
0: Asyn. motor open-loop vector control
1: Asyn. motor closed loop vector control
2: Syn. motor closed loop vector control
3: Asyn. motor flux vector control
3
×
F01: Motor Parameter, on page 25
F01.00 Motor rated power 1 - 750W 250W
×
F01.01 Motor rated voltage 1 - 300V 220V
×
F01.02 Motor rated current 0.10 - 2.50A 0.55A
×
F01.03 Motor rated frequency 1.00 - 99.99Hz 50.00Hz
×
F01.04 Motor rated Rpm 1 - 6000rpm 900rpm
×
F01.05 Reduction ratio 1.00 - 9.99 1.00
×
F01.06 Motor parameter auto-tuning
0: No action
1: Motor parameter auto-tuning
0
×
F01.07 No load current 0.01 - 2.50A 0.36A
×
F01.08 Magnetic pole position angle 0.0 - 359.9 0.0
×
F01.09 Stator resistance 0.00 - 99.99Ω
Depend
on
MONT20
×
F01.10 Rotor resistance 0.00 - 99.99Ω
×
F01.11 Stator inductance 0 - 9999mH
×
F01.12 Rotor inductance 0 - 9999mH
×
F01.13 Mutual inductance 0 - 9999mH
×
F01.14 Slip compensation gain 50.0 - 200.0% 100.0%
×
