hpmont MONT20 User Manual

Appendix A Parameter
62 MONT20 User Manual V1.6
R
ef. Code Function Setting Range Default Attribute Setting
F02: Encoder Door Width Parameter, on page 26
F02.00 Pulse per rpm of encoder 0 - 9999 1024
×
F02.01 Encoder direction setting
0: Same direction
1: Opposite direction
1
×
F02.02 Slow running speed setting 0.01 - 15.00Hz 7.00Hz
○
F02.03
Initial running speed after
power on
0.01 - 15.00Hz 7.00Hz
○
F02.04
Door width self-learning
speed
0.01 - 15.00Hz 4.00Hz
○
F02.05
Door width self-learning
enable
0: Invalid
1: Door width self-learning mode 1 is valid
2: Door width self-learning mode 2 is valid
0
×
F02.06 Low bit of door witdh 0 - 9999 (pulse number) 780
×
F02.07 High bit of door witdh 0 - 9999 (pulse number) 0
×
F02.08
CD limit open/close position
pulse
0 - 9999 0
×
F03: OD Curve Parameter, on page 27
F03.00
OD start distance/OD start
time
Distance control: 0 - 9999 (pulse number)
Speed control: 0 - 9999 (ms)
1000
○
F03.01 OD start speed 0.00 - 15.00Hz 3.50Hz
○
F03.02 OD Acc. time 0.1 - 99.9s 1.3s
○
F03.03 OD speed 0.00Hz - F00.04 20.00Hz
○
F03.04 OD Dec. point position 50.0 - 90.0% (door width) 65.0%
○
F03.05 OD Dec. time 0.1 - 99.9s 1.4s
○
F03.06 Creeping speed at OD ending 0.00 - 15.00Hz 3.00Hz
○
F03.07 OD limit point position 80.0 - 99.9% (door width) 95.0%
○
F03.08
High-speed area of re-
opening curve
10.0 - 90.0% (door width) 90.0%
○
F04: CD Curve Parameters, on page 28
F04.00
CD start distance/CD start
time
Distance control: 0 - 9999 (pulse number)
Speed control: 0 - 9999 (ms)
0
○
F04.01 CD start speed 0.00 - 15.00Hz 4.00Hz
○
F04.02 CD Acc. time 0.1 - 99.9s 1.4s
○
F04.03 CD speed 0.00Hz - F00.07 18.00Hz
○
F04.04 CD Dec. point position 50.0 - 90.0% (door width) 62.0%
○
