hpmont MONT20 User Manual

Appendix A Parameter
MONT20 User Manual V1.6 63
Ref. Code Function Setting Range Default
Attribute
Setting
F04.05 CD Dec. time 0.1 - 99.9s 1.3s
○
F04.06 Creeping speed at CD ending 0.00 - 15.00Hz 3.00Hz
○
F04.07
Door vane acting position at
CD ending/running time at
CD ending creeping speed
Distance control: 1 - 5000 (pulse number)
Speed control: 1 - 5000 (ms)
0
○
F04.08
Door vane action speed at CD
ending
0.00 - 15.00Hz 0.00Hz
○
F04.09 CD limit point position 1 - 500 60
○
F04.10
Door vane retiring end speed
of Asyn. CD
0.00 - 5.00Hz 0.00Hz
○
F04.11
CD ending range of Asyn.
door vane CD/running time of
CD ending Asyn. door vane
action speed
Distance control: 0 - 5000 (pulse number)
Speed control: 0 - 5000 (ms)
0
○
F05: Torque Parameter, on page 29
F05.00 OD switching torque 20.0% - F07.07 50.0%
○
F05.01 OD holding torque 30.0% - F07.07 45.0%
○
F05.02
Final holding torque at
complete OD
0.0% - F07.07 35.0%
○
F05.03
Switching time from OD
holding torque to final
holding torque
0.1 - 999.9s 30.0s
○
F05.04 CD switching torque 20.0% - F07.07 50.0%
○
F05.05 CD holding torque 30.0% - F07.07 45.0%
○
F05.06
Final holding torque of
complete CD
0.0% - F07.07 35.0%
○
F05.07
Switching time from CD
holding torque to final
holding torque
0.1 - 999.9s 60.0s
○
F05.08
Torque setting at low speed
CD resistance
0.0% - F07.07 80.0%
○
F05.09
Time at low speed CD
resistance
0 - 4999ms 1000ms
○
F05.10
Torque setting at high speed
CD resistance
0.0% - F07.07 80.0%
○
F05.11
Time of high speed CD
resistance
0 - 4999ms 1000ms
○
