hpmont MONT20 User Manual

Appendix A Parameter
64 MONT20 User Manual V1.6
R
ef. Code Function Setting Range Default Attribute Setting
F05.12
Low speed setting at CD
resistance
0.00Hz - F00.07 5.00Hz
○
F05.13
High speed setting at CD
resistance
5.00Hz - F00.07 15.00Hz
○
F05.14
Switching torque of low speed
OD/CD
30.0% - F07.07 70.0%
○
F05.15 Torque at OD resistance
0.0% - F07.07
0.0%: Invalid
100.0%
○
F05.16 Time at OD resistance 0 - 4999ms 1600ms
○
F05.17 Stop time at OD resistance 0 - 9999ms 3000ms
○
F06: Boost Parameters, on page 30
F06.00
DOA, DCA, PA output pole
selection
0: Signal connects
1: Signal disconnects
1
×
F06.01 PA function selection
0: Door position output
1: Re-opening signal outputs at CD resistance
2: Complete OD
3: Complete CD
4: Fault output
5: Running (normally open)
6: Door vane solenoid valve output (normally
open)
7 - 9: Unused
10: Door position output (normally closed)
11: CD resistance re-opening signal output
(normally closed)
12: Complete OD (normally closed)
13: Complete CD (normally closed)
14: Fault output (normally closed)
15: Running (normally closed)
16: Door vane solenoid valve output
(normally closed)
17 - 19: Unused
0
×
F06.02 Input terminal filter time 2 - 300ms 10ms
×
F06.03 DI1 funtion selection
0: No funtion
1: OD speed switching normally open (NO)
input
11
×
