hpmont MONT20 User Manual

Appendix A Parameter
MONT20 User Manual V1.6 65
Ref. Code Function Setting Range Default
Attribute
Setting
F06.04 DI2 funtion selection
2: OD limit NO input
3: CD speed switching NO input
4: CD limit NO input
5: Light curttain, contact board NO input
6: Low speed signal (SS)
7: OD command (OD)
8: CD command (CD)
9: Fault reset (RST)
10: Motor overheating normally open input
11: OD speed switching NC input
12: OD limit NC input
13: CD speed switching NC input
14: CD limit NC input
15: Light curtain, touch board NC input
20: Motor overheating NC input
21: The door lock signal is normally open
22: The door lock signal is normally closed
12
×
F06.05 DI3 funtion selection 13
×
F06.06 DI4 funtion selection 14
×
F06.07 DI5 funtion selection 0
×
F06.08
DC resistance Aux. detection
time
0 - 4999ms 0ms
×
F06.09
Percentage of door position
output
0.1 - 99.9% 90.0%
○
F06.10 Resistance Dec. time 0.1 - 2.0s 0.5s
○
F06.11
Action selection of door
motor when revoke run
command
0: The torque is maintained during complete
OD/CD, and runs at zero speed in other
position
1: Stop running
2: Only maintain the torque during complete
OD/CD
2
○
F06.12 Auxiliary parameter 1
Ten thousand: Detect CD resistance 1/3
distance from CD acts
0: Detect CD resistance
1: Not detect CD resistance
Thousand: Function of stop key in terminal
control
0: Invalid
1: Valid
00000
○
