Appendix A Parameter
68 MONT20 User Manual V1.6
R
ef. Code Function Setting Range Default Attribute Setting
0: No action
F07.02 Low speed ASR KP 10 - 3000 500
○
F07.03 Low speed ASR KI
0 - 1000
0: No action
100
○
F07.04 ASR switching frequency 0.00Hz - F00.04 8.00Hz
○
F07.05 Current loop KP 10 - 9999 100
○
F07.06 Current loop KI 0 - 9999 100
○
F07.07 Torque limit 0.0 - 200.0% (motor rated current) 120.0%
○
F07.08 Speed filter time constant 0 - 7 2
×
F08: Demo Running Parameter, on page 36
F08.00
Demonstrate the retention
time of running complete OD
1.0 - 999.9s 2.0s
○
F08.01
Demonstrate the retention
time of running complete CD
1.0 - 999.9s 2.0s
○
F08.02
Demonstrate the running
times record
0 - 65535 0
○
F08.03
Demonstrate the nominated
running times
0 - 65535 0
○
F09: Fault Record Parameters, on page 37
F09.00 NO.5 fault type
-Lu-: DC bus under voltage
E0001: MONT20 over-voltage
E0002: Hardware of MONT20 is over-current
E0003: Software of MONT20 is over-current
E0004: Encoder Z signal of PMSM is lost
E0006: Motor parameter auto-tuning failed
E0007: MONT20 overloaded
E0008: Permanent magnet Syn. motor first
current detection is too small
E0009: Motor overload fault
E0010: Abnormal opening fault
E0011: Motor overheating fault
E0012: Abnormal closing fault
E0014: Read/write fault of MONT20 EEPROM
E0015: Speed deviation is too large
E0016: Overspeed fault
E0017: Module fault
Actual
value
*
F09.01 NO.4 fault type
F09.02 NO.3 fault type
F09.03 NO.2 fault type
