hpmont MONT20 User Manual

Appendix A Parameter
MONT20 User Manual V1.6 67
Ref. Code Function Setting Range Default
Attribute
Setting
F06.19
Flux vector complete CD
holding frequency
0.10 - 5.00Hz 1.00Hz
○
F06.20
Flux vector complete OD
holding frequency
0.10 - 5.00Hz 1.00Hz
○
F06.21
Delay switching time of flux
vector speed switching to
torque
100 - 3999ms 2500ms
×
F06.22
Frequency range of flux vector
no detection OD/CD
resistance
0.10 - 15.00Hz 7.00Hz
×
F06.23
Flux vector OD voltage
compensation
0 - 8% 0%
×
F06.24
Cut-off point of flux vector
voltage compensation
frequency
10.00 - 50.00 50.00
×
F06.25 Auxilliary parameter 3
Unit: DO signal keeping when first time
power up under distance control
0: Do not keep
1: Keep
Ten: Address setting under CAN control
0: Front door
1: Rear door
Hundred: Electric angle search for permanent
magnet Syn. motor (PMSM)
0: Current method
1: Pulse method
Thousand: Motor overload protection shield
0: No shield
1: Shield
Ten thousand: Open door abnormal
shutdown protection open
0: Open
1: Not open
00000
×
F07: Vector Control Parameter, on page 35
F07.00 High speed ASR KP 10 - 3000 500
○
F07.01 High speed ASR KI 0 - 1000 100
○
