Appendix A Parameter
MONT20 User Manual V1.6 69
Ref. Code Function Setting Range Default
Attribute
Setting
F09.04 NO.1 fault type
E0018: Current detection circuit fault
E0022: Read/write fault of keypad EEPROM
E0023: Encoder fault
E0024: Wrong logic
E0026: Door width self-learning failed
F09.05 Bus voltage of last fault 0 - 999V Actual *
F09.06 Output current of last fault 0.00 - 99.99A Actual *
F09.07
Running frequency of last
fault
0.00 - 99.99Hz Actual *
F09.08 Setting frequency of last fault 0.00 - 99.99Hz Actual *
F09.09 Door position of last fault 0 - 65535 Actual *
F09.10
Input terminal status 1 of last
fault
00000 - 11111 Actual *
F09.11
Input terminal status 2 of last
fault
000 - 111 Actual *
F09.12
Output terminal status of last
fault
000 - 111 Actual *
F09.13
Low bit of OD/CD times
record
0 - 9999 Actual *
F09.14
High bit of OD/CD times
record
0 - 9999 Actual *
F09.15 Runnning hours record 0 - 23 Actual *
F09.16 Running days record 0 - 9999 Actual *
F09.17 Controller software version 1.00 - 99.99 Actual *
F09.18 Keypad software version 1.00 - 99.99 Actual *
F10: Advanced Parameters, on page 38
F10.00
Electromagnetic valve door
vane opening delay time
0 - 9999ms 0ms
○
F10.01
Electromagnetic valve door
vane closing delay time
0 - 9999ms 0ms
○
F10.02 OD creeping time 0.0 - 5.0s 0.7s
○
F10.03 CD creeping time 0.0 - 5.0s 0.7s
○
F10.04 Door vane distance 0 - 9999 pulse 0 pulse
○
F10.05
Automatical generation of
switch door curve Dec. point
0: By parameter setting
1: Automatic calculation by software
0
○
F10.06
OD holding torque
automatically calculated
