FusionModule800 Smart Small Data Center
Installation Guide (Six Fans)
Copyright © Huawei Technologies Co., Ltd.
Arrange at least two persons to move the mounting bars.
Exercise caution when moving mounting bars to avoid deforming the cabinet bottom
panel.
1. Remove the baffle plate secured to the top of the mounting bars on the front door side, as
shown in Figure 3-33.
Figure 3-33 Removing the baffle plate
2. Remove the guide rails.
