FusionModule800 Smart Small Data Center
Installation Guide (Six Fans)
Copyright © Huawei Technologies Co., Ltd.
Figure 3-34 Removing guide rails
3. Remove screws from the mounting bar and move the entire mounting bar 50 mm
towards the cabinet exterior, as shown in Figure 3-35.
To remove one mounting bar, remove the four screws from the upper and lower and the four screws
in the middle that secure the mounting bar to the cabinet.
If there are guide rails fixed on mounting bars, remove the guide rails before moving the mounting
bars.
