iManager NetEco 6000
Device Installation and Commissioning Guide
Copyright © Huawei Technologies Co., Ltd.
Figure 7-24 Removing the base
Step 4 Separate the base from the magnetic lock using a hex key, as shown in Figure 7-25. Unpack
and take out a new magnetic lock.
Figure 7-25 Separating a magnetic lock
Step 5 Install the new magnetic lock.
1. Remove the fixing plate from the magnetic lock using the delivered hex key as shown in
Figure 7-26.
The four hex socket screws should be removed in this step.
