Hunter X-CORE User Manual

I-CORE: INSTITUTIONAL/COMMERCIAL CONTROLLER
(IC-600PL & IC601PL) – PLASTIC CABINET
Item Description Catalog No.
Front Panel 124705
Knob 129300
Rear Cabinet 117805
Door Without Lock, Plastic I-Core 131305
Lock & Key Set 387300
Key Set (2) 122516
6-Station Expansion Module ICM600
48 Station DUAL Module DUAL48M
Transformer 154628
Junction Box 123800
Junction Box Cover 124000
Smart Port Wiring Harness
25' Shielded Cable
SRR-SCWH
Power Module 121405
Ribbon Cable, Plastic I-Core 130800
I-Core Mounting Template LIT-548
Hanging Door Card English LIT-506
Owners Manual English LIT-502
International Kit
(Includes Owners
Manual)
Spanish INT-895
French INT-894
Italian INT-896
German INT-898
Portuguese INT-897
