Hunter X-CORE User Manual

I-CORE: INSTITUTIONAL/COMMERCIAL CONTROLLER
(IC-800M & IC-800SS) – METAL CABINET
Item Description Catalog No.
Front Panel 124705
Knob 129300
Door Without Lock, Metal I-Core 125500
Lock & Key set 387300
Key Set (2) 122516
Rear Cabinet 118700
6 Station Expansion Module ICM600
48 Station DUAL Module DUAL48M
Transformer 154628
Junction Box 123800
Junction Box Cover 124000
Smart Port Wiring Harness
25' Shielded Cable
SRR-SCWH
Power Module 121405
Ribbon Cable, Metal/Stainless I-Core 130810
I-Core Mounting Template LIT-548
Hanging Door Card English LIT-506
Owners Manual English LIT-502
International Kit
(Includes Owners
Manual)
Spanish INT-895
French INT-894
Italian INT-896
German INT-898
Portuguese INT-897
6
7
8
9
1
2
4
5
3
10
11
12
37
3
5
6
9
12
7
10
11
1
2
SET CURRENT DATE / TIME
SET PROGRAM START TIMES
SET STATION RUN TIMES
SET DAYS TO WATER
SET SEASONAL ADJUSTMENT
SET PUMP OPERATION
SYSTEM OFF
MANUAL OPERATION
ADVANCED FEATURES
SET SENSOR OPERATION
CYCLE AND SOAK
RAIN SENSOR
ACTIVE BYPASS
SETTINGS
4
8

Hunter X-CORE Specifications

General

Start Times Per Program	4
Max Station Run Time	4 hours
Warranty	2 years
Application	Residential
Mounting	Wall mount
Station Timing	1 minute to 4 hours
Number of Stations	2, 4, 6, or 8
Watering Duration	1 minute to 4 hours
Display	LCD
Stations	2, 4, 6 or 8 stations
Indoor/Outdoor	Indoor or Outdoor
Seasonal Adjustment	Yes
Watering Days	7 days
Rain Delay	Yes
Power Source	24V AC transformer
Battery Backup	Yes
Programs	3
