A. – LCD Display
1. Program Selector – Identifies the program in use A, B, or C.
2. Station Number – Identifies currently selected station number.
3. Main Display – Indicates various times, values, and programmed
information.
4. Year – Identifies current calendar year.
5. Month – Identifies current calendar month.
6. Day – Identifies current calendar day.
7. Running – Sprinkler icon indicates when watering is occurring.
8. Days of the week – Identifies days of the week to water or
not water.
9. Odd/Even Watering – Identifies if odd or even watering is selected
.
10. Interval – Identifies if interval watering has been selected.
11. Seasonal Adjust – Displays in increments of 5%, the percentage
of seasonal adjust that has been selected.
12. Start Time – Identifies selected program start time.
B. – Control Buttons and Switches
13. Button – Increases the selected flashing display.
14. Button – Decreases the selected flashing display.
15. Button – Returns selected flashing display to the previous item.
16. Button – Advances the selected flashing display to the
next item. Also to start a manual cycle.
17. Button – Selects programs A, B, and C. Also to start
a test program.
18. Rain Sensor Bypass Switch – Use to bypass weather sensor, if
one is installed.
C. – Control Dial
Run – Normal dial position for automatic operation.
Set Current Date/Time – Set current date time.
Set Program Start Times – Set 1 to 4 start times in each program.
Set Station Run Times – Set each station run time.
Set Days to Water – Select individual days to water, odd, even, or
interval watering schedule.
Set Pump Operation – Turn pump or master valve on or off for each
station.
Manual – Single Station – Activates a one time watering of a single
station.
Seasonal Adjustment – Make global run time changes without repro-
gramming the controller (from 5% to 300%).
System Off – Used to discontinue all programs and stop all watering
until the dial is returned to the RUN position, or to set the program-
mable rain off feature.
D. – Wiring Compartment
20. 9-Volt Battery – An alkaline battery (not included) allows you to
program the controller without AC power.
21. Reset Button – This button will reset the controller.
All programmed data will remain intact.
22. Power Area – Used to attach transformer, sensor wires, and other
systems to the controller.
23. Transformer – A transformer is installed (Outdoor models only,
indoor models are supplied with a plug-in transformer.)
24. Junction Box – This box provides an area for connecting primary AC
power. (Outdoor models only.)
25. Ground Lug.
